Portable Mobile small batch oil fired incinerator

Portable Mobile small batch oil fired incinerator, vortex circulation technology, equipped with air blower, combustion chamber 0.2m3, burn rate for mixed waste 20kg/hr, operational temperature min 800-1000°C, average ash residue 3%, gas retention time min 0.5 sec, electrical consumption 0.5 kw/hr, barrel type with front loading access, three heavy duty tires, two handles and easy ash remove function, shipping weight max 900 kg, Italy Baltur Oil Burner.

Equipment Technical Specifications
Model	YD-20
Burning Rate	Average 20 kgs per hour
Voltage	220V 1P
Power	0.5Kw
Fuel	Diesel oil
Burner	Italy Burner *2 sets
Feed Mode	Manual
Fuel consumption (Oil)	Average 8.4 Kgs/Hour
External Dimensions	100 x 100 x 180cm (main body)
Internal Dimensions	Dia.50x 80cm(Primary Chamber)
Waste combustion chamber	200Liters
Post Combustion Chamber	100Liters
Oil Tank Capacity	50 Liters
Feeding Door Opening	30 x 20cm
Chimney	1.0M
Gross Weight	900kgs
Chamber Material	Refractory Concrete
Operation Technical Specifications
Chamber temperature	800⁰C -1000⁰C
Chamber Anti-Rate	1350⁰C
Residency time	0.5 Sec.
Burning efficiency	＞98%
Waste Lower Calorific Power	3500Kcal
