Pet crematorium up to 200KG/day

Animal Crematory Incinerator

Capacity: Average 80kgs per feeding



Item

Specification

Model

A900

Internal Dimensions

120 x 90 x 85 CM

Suit for Animal

Cat – yes

Dog – yes

Pig – small

Cow – no

Main Product List

Primary Combustion Chamber

Secondary Combustion Chamber

Mix-Combustion Chamber

Smoke Filter Chamber

Incinerator Control Case

Chimney:5.0Meters

*(upgrade to Stainless Steel, free cost)

Italy oil/gas burner: 03 sets

Oil Tank (if oil fuel): 500Liters

















Model

A900


Burning Rate

Average 30 kgs/hour

Feed Capacity

Average 80 kgs/feeding

Primary Combustion Chamber

900 Liters

Secondary Combustion Chamber

300 Liters

Mix Combustion Chamber

Yes

Smoke Filter Chamber

Yes

Feed Mode

Manual

Voltage

220V/380V

Power

1.5 Kw

Fuel Type

Diesel Oil/ Natural Gas/LPG

Burner

Italy Original

Oil Consumption (Diesel Oil)

Average 34 kg/hour

Gas Consumption (Natural Gas)

Average 41 m3/hour

Internal Dimensions

120 x 90 x 85 cm (primary chamber)

External Dimensions

200 x 160 x 310 cm (without chimney)

Temperature Monitor

Yes

Oil Tank Capacity(if oil fuel)

500 Liters

Door Opening

60 x 80cm

Chimney Length

5.0 Meters

Chimney Type

Stainless Steel

Combustion Chamber Material

Refractory Concrete Cement(No Brick)

Equipment Gross Weight

6000 kgs

Operation Technical Specifications

Primary Chamber Temperature

800-1000

Secondary Chamber Temperature

1000-1200

Residency Time

2.0 Sec.

Burning Efficiency

98%

Waste Lower Calorific Power

3000Kcal
