Hot Medical Waste Disposing MachineOperation Condition 8-16 Hr /dayControls Built in data recordingIncinerator /Primary Combustion Chamber Type: continuous loading Capacity/Burn rate per hour: 250 -300kg/hr Temperature: 900-1200 oC Material:External- 3 layers Internal lining: a fire proof material of pre-fired refractory bricks with Aluminium lining, resistant to corrosive waste or gas and to thermal shockSecondary Combustion Chamber Type: horizontal/vertical Temperature: 1200-1400 oC Residence time of gases : >2 seconds MaterialExternal- Low thermal mass insulation 14-30 oC Internal lining: a fire proof material of pre-fired refractory bricks with Aluminium nettle lining, resistant to corrosive waste or gas and to thermal shock.Ash Handling System Both Automatic and manual removal of Ash. Must ensure removal/treatment of hazardous remnants of ash.Flue gas treatment system Capable of treating the flow of flue gas as the incinerator is operating at its maximum capacity Auxiliary device: Water level gauge, pressure sensor, PH sensor..etc. Auxiliary device: Fuel cut off deviceWaste feeding mechanism Automatic pneumatic/hydraulic waste loading system or conveyor belt , capacity 650-800L at a time Chimney (Stack) Type: Vertical type height: 7-10 meters Material: Fireproof cast, stainless steel Wet scrubbing system Vertical sprat tower with baffles or packing insideGas emission Reduction of Pollutant gas SO2, HCL, HF and line particulateOUTPUT ASH -Max <5% of original waste size GAS- SMOKELESS,ODORLESSEmission standard WHO/ EuropeanTest report for emission testing…
